Feed mixer structure feature:
The feed crushing mixer shell is welded by high-quality materials. The feeding inlet is on the top of the crusher and can be matched with various forms of feeding structure. The hammer pieces are arranged symmetrically. When the feed mixer is working, the material enters the crusher chamber and rotates at high speed. Under the action of the hammer and the sieve plate, the material is gradually crushed and discharged through the bottom discharge port under the action of centrifugal force and air flow.
Application:
Designed for rural farmers, small-scale farms, small and medium-sized compound feed mills, small feed processing equipment, vertical lifting, mixing warehouse, horizontal conveying; integrated structure, simple and compact, one-time small investment, economical and practical, easy maintenance It does not require special production sites; it is evenly mixed, and can produce premixes, concentrated materials, full-price powders, etc. suitable for small-scale farmers, pigs, cattle, horses, rabbits, chickens, fish, etc. With functional models such as crushing, this machine is a small compound feed processing equipment designed for rural farmers, small-scale farms, small and medium-sized compound feed mills. It integrates vertical lifting, mixing bins and horizontal conveying; it has a simple and compact structure. One-time small investment, economical and practical, convenient maintenance, no special production site, etc.; evenly mixed, can produce premix, concentrated material, full price powder, etc.
Main parameter:
Model Power (kw) Capacity (kg/batch) Speed (r/min) Blade width (mm) Wight (kg) Size (mm) Shaft diameter (mm)
AIX-100 3 100 20 50*6 300 1600*700*1400 76
AIX-200 4 200 20 50*6 400 1800*700*1500 76
AIX-300 5.5 300 18 50*6 600 2200*900*1600 80
AIX-500 7.5 500 18 60*8 800 2400*1000*1700 89
AIX-1000 11 1000 15 60*8 1000 2800*1200*2000 89
AIX-1500 15 1500 15 60*8 1500 3200*1300*2200 89
AIX-2000 18.5 2000 12 60*10 1800 3500*1500*2300 108
AIX-2500 22 2500 12 60*10 2300 3800*1600*2500 108
AIX-3000 30 3000 12 60*10 2600 4100*1700*2700 127
AIX-4000 37 4000 12 70*12 6000 4300*1800*2800 127
AIX-5000 45 5000 12 70*12 3500 5000*2000*3000 136
Advantage:
1. The feed mixer is a horizontal U-shaped cylinder. The inner and outer two-layer spiral belt has a unique structure, stable operation, reliable quality, low noise, long service life, convenient installation and maintenance, and a variety of agitator structures. Multifunctional mixing device.
2. It has high efficiency, fast mixing speed and high mixing evenness. Especially the viscous spiral belt can be equipped with a scraper, which is more suitable for thick and mushy mixing.
3. high precision, different spiral belt structure under the mixing requirements of different materials.
4. Good stability, stable operation, reliable quality, low noise, long service life and convenient installation and maintenance.
